MAZAK CNC Turning Centre QTN 200II (2007) (2007)

MACHINE REF :12012

Machines For Sale — . Lathe, CNC Fixed Head

MAKE :MAZAK CNC Turning Centre

MODEL :QTN 200II (2007)

YEAR OF MANUFACTURE :2007

CONTROLLER :NEXUS

SPECIFICATION :YOM: 2007 Model: QTN-200II Max. swing dia.: 610mm Max. machining dia.: 350mm Bar capacity: 65mm Spindle speed: 5,000rpm X/Z axis travel: 225/535mm Mazatrol NEXUS control

DESCRIPTION :without CE Marking

PEDDINGHAUS Combined Punch press/press brake FORAX 45 with tooling

MACHINE REF :12017

Machines For Sale — . Sheet Metal & Plate, Punch Press

MAKE :PEDDINGHAUS Combined Punch press/press brake

MODEL :FORAX 45 with tooling

AFM FABTEK Guillotine Shear, visible under power MK 13-31, capacity 13x3100 mm, weight 12 t, controlled back gauge (2000)

MACHINE REF :12024

Machines For Sale — . Sheet Metal & Plate, Shear/Guillotine

MAKE :AFM FABTEK Guillotine Shear, visible under power

MODEL :MK 13-31, capacity 13x3100 mm, weight 12 t, controlled back gauge

YEAR OF MANUFACTURE :2000

CONTROLLER :FABTEK

DOOSAN CNC Turning Centre, 2off required, late machines 3100 LY/1000 mm, 1st live turret, 2nd static turret, hydraulic tailstock

MACHINE REF :12028

Wanted Machines — . Lathe, CNC Fixed Head

MAKE :DOOSAN CNC Turning Centre, 2off required, late machines

MODEL :3100 LY/1000 mm, 1st live turret, 2nd static turret, hydraulic tailstock

CONTROLLER :CNC

YASDA HMC YBM 80N - twin pallet 630mm + FMS, much tooling, 400 ATC (1991)

MACHINE REF :12030

Machines For Sale — . Machining Centre, Horizontal - FMS

MAKE :YASDA HMC

MODEL :YBM 80N - twin pallet 630mm + FMS, much tooling, 400 ATC

YEAR OF MANUFACTURE :1991

CONTROLLER :Fanuc 15M

SPECIFICATION :Pallets 630 X 900 Y 800 Z 750 BT50 360 deg b axis Fanuc 15M

DESCRIPTION :1991 machine, good working order, price includes loading to trucks

HOESCH MFD CNC Heavy Duty Centre Lathe - EXLOADED D-1600 FN-YF- 1, capacity 1600x12000 mm, threading, grinding, steadies, swarf (1984)

MACHINE REF :12035

Machines For Sale — . Lathe, CNC Fixed Head >=2m b/c

MAKE :HOESCH MFD CNC Heavy Duty Centre Lathe - EXLOADED

MODEL :D-1600 FN-YF- 1, capacity 1600x12000 mm, threading, grinding, steadies, swarf

YEAR OF MANUFACTURE :1984

CONTROLLER :SIEMENS SINUMERIK System 8

Swarf Conveyors and Belts, brand new, directly from the manufacturer

MACHINE REF :12039

Machines For Sale — . Swarf, Conveyors

MAKE :Swarf Conveyors and Belts, brand new, directly from the manufacturer

SPECIFICATION :Please check pictures for specifications. Prices upon application.

UNION Table Type Horizontal Borer - EXLOADED BFT 90/3, spindle 9025 mm, XY 1000x1000 mm, table 1000x1120 mm, 9,3 t

MACHINE REF :12042

Machines For Sale — . Borer, Horizontal Table

MAKE :UNION Table Type Horizontal Borer - EXLOADED

MODEL :BFT 90/3, spindle 9025 mm, XY 1000x1000 mm, table 1000x1120 mm, 9,3 t

CONTROLLER :conventional

TOS Gear Hobber - OFFERS INVITED - TEMPORARILY ON HOLD FO-10, gear dia 1000 mm, module 10

MACHINE REF :12048

Machines For Sale — . Gear, Hobber

MAKE :TOS Gear Hobber - OFFERS INVITED - TEMPORARILY ON HOLD

MODEL :FO-10, gear dia 1000 mm, module 10

CONTROLLER :conventional

wanted Heavy Duty HEADSTOCK for Lathe 20 ton unsupported capacity - facaing lathe type

MACHINE REF :12052

Wanted Machines — . Lathe, Facing

MAKE :wanted Heavy Duty HEADSTOCK for Lathe

MODEL :20 ton unsupported capacity - facaing lathe type

NILES Gear Grinders (3 off) ZSTZ 630 models C2 C3 and C3P

MACHINE REF :12058

Machines For Sale — . Gear, Grinder

MAKE :NILES Gear Grinders (3 off)

MODEL :ZSTZ 630 models C2 C3 and C3P

SPECIFICATION :3 X GEAR GRINDING MACHINE TYPE ZSTZ 630 C2 TYPE ZSTZ 630 C3 TYPE ZSTZ 630 C3P

DESCRIPTION :loaded to truck or container

AMC Schou CNC Cylindrical / Crankshaft Grinder R2400 CE CNC (1997) - Dual 300mm chucks, steadies, Siemens control (1997)

MACHINE REF :12064

Machines For Sale — . Grinder, Cylindrical CNC

MAKE :AMC Schou CNC Cylindrical / Crankshaft Grinder

MODEL :R2400 CE CNC (1997) - Dual 300mm chucks, steadies, Siemens control

YEAR OF MANUFACTURE :1997

CONTROLLER :Siemens

SPECIFICATION :AMC Schou R2400 CE CNC Cylindrical Grinder Dual 300mm dia chucks, steadies, with Siemens Sinumerik Control & Losma 700mm Filter Band.

DESCRIPTION :Machine is like new and is only worked a few weeks every year.

CHARMILLES Erosion Machine ROBOFORM 31 (1999) with robot (1999)

MACHINE REF :12066

Machines For Sale — . Eroder, Spark

MAKE :CHARMILLES Erosion Machine

MODEL :ROBOFORM 31 (1999) with robot

YEAR OF MANUFACTURE :1999

SPECIFICATION :table area: 500x400 mm X/Y/Z: 350/250/300 mm Linear robot with changer: 16 pcs

SCHAUBLIN Vertical Machining Centre - 4-AXES 33CNC, X-520 mm, Y-320 mm, Z-320 mm (1991)

MACHINE REF :7501

Machines For Sale — . Machining Centre, Vertical

MAKE :SCHAUBLIN Vertical Machining Centre - 4-AXES

MODEL :33CNC, X-520 mm, Y-320 mm, Z-320 mm

YEAR OF MANUFACTURE :1991

CONTROLLER :SIEMENS SINUMERIC 3

SPECIFICATION :X-520 mm, Y-320 mm, Z-320 mm, 64 posts ATC, SIEMENS SINUMERIC 3 controller

ZVL Surface Grinder, very clean machine BRH-20A, table 200x630 mm, weight 2 t (1988)

MACHINE REF :12401

Machines For Sale — . Grinder, Surface Recip Table

MAKE :ZVL Surface Grinder, very clean machine

MODEL :BRH-20A, table 200x630 mm, weight 2 t

YEAR OF MANUFACTURE :1988

MITSUBISHI CNC Gear Grinder ZG-1000 CNC - 1m capacity - 5 axis - Many spares, tooling, equipment

MACHINE REF :4684

Machines For Sale — . Gear, Grinder

MAKE :MITSUBISHI CNC Gear Grinder

MODEL :ZG-1000 CNC - 1m capacity - 5 axis - Many spares, tooling, equipment

CONTROLLER :Mitsubishi

SPECIFICATION :Mitsubishi ZG-1000CNC, full CNC gear form grinding machine manufactured by Mitsubishi Heavy Industries, Ltd., of Japan, complete with a FANUC 16MA numerical control and electrical equipment to operate from 230 volts, 3 phase, 60 hertz, AC line. A) SPECIFICATIONS Workpiece Maximum workpiece diameter ... 39.37" (1000mm) Maximum diametral pitch/module ... 1.41 DP/18 M Maximum swiveling angle ... ±45° Center distance from wheel spindle to center of work table Maximum ... 27.56" (700mm) Minimum 3.93" (l00mm) Maximum radial travel 23.62" (600mm) Height work table to center of wheel spindle Maximum … 33.46" Minimum … 5.91 (150mm) A) SPECIFICATIONS ('continued') Maximum axial travel Distance between worktable and tailstock Maximum Minimum Maximum stroke (Optionally can be increased to 31.50" (800mm) Maximum worktable speed Maximum wheel diameter Feed rates X - axis (radial) Y - axis (wheel shift axis) Z - axis (longitudinal axis) Rapid traverse X - axis (radial) Y - axis (wheel shift axis) Z - axis (longitudinal axis) A - axis (wheel head swivel axis) C - axis (table axis) 27.56 (700mm) 30.91" (785mm) 11.22" (285mm) 19.69" (500mm) 33 rpm (rapid) 10 rpm (feed) 11.81 (300mm) 0.0004" - .787"/min (0.01 - 20mm/min) 0.0004" - .787"/min (0.01 - 20mm/min) 0.0039" - 196.9"/min (0.1 - 5,000mm/min) 196.9"/min (5,000mm/min) 39.4"/min (l.000mm/min), 196.9"/min (5,000mm/min) 196.9"/MIN. (5,000mm/min) 15 rpm A) SPECIFICATIONS (continued) Main Spindle Motor (Wheel head) ... 14.8 hp (1 Ikw) AC spindle (30 min rated) Main Spindle Rotation ... 200 - 6000 rpm Height - floor to worktable ... 48.6" (1 ,235mm) Machine total height ... 131.1" (3,330mm) Floor space ... 128.9" X 197.6" (3275mm X 5020mm) Net weight . . . 35,275 Ibs (16,000 kg) B) FEATURES 5 - Axis CNC controlled machine. Up to 90% reduction in set-up and changeover times, compared to conventional type machine. All cutting conditions are automatically calculated by conversational "menu" type programming, including feeds, speeds and wheel profiles. Mitsubishi planetary traction table drive unit for improved indexing accuracy and reduced indexing time. Linear scale feedback control for radial and sliding axes and high resolution rotary-scale feedback for work table control. Main spindle oil chiller is provided, along with automatic thermal compensation, for each axis. CBN capable. C) SPECIFICATIONS OF CNC CONTROL SYSTEM (FANUC 16MA) 1. Number of numerically controlled axes: The following 5 axes are numerically controlled: (6th axis optional) X - axis for radial feed Z - axis for axial feed C - axis for table rotation Y - axis for wheel shift 2. Minimum input increment 3. Interface 4. Length of memory tape: 5. Door interlock 6. Machine operation by MDI 7. Machine operation by memory A - axis for wheel head swivel (U – axis for optional truing/dressing device) 0.00004" for "X", "Y" and "Z" axes 0.0001° for "C" and "A" axes RS232C 150m 8. Self-diagnosis functions (Displays both machine and NC malfunctions) 9. Automatic programming functions (Auto-calculation of grinding conditions from input of workpiece and wheel specifications) 10. Size compensation Three (3) types are provided, including: "over ball/over wire diameter" "base tangent length" "radial dimension" D) ACCURACY FEATURES ± 3 arc seconds indexing accuracy E) ZG1000 STANDARD EQUIPMENT (1) Hydraulic oil system with automatic temperature control. (2) Intermittent oil lubrication system. (3) Coolant system with paper and cartridge media. (4) Sliding way covers. (5) Full machine enclosure. (6) Oil mist collector. (7) Door interlock device. (8) Support Center. (9) Automatic wheel head clamping device. (10) Automatic thermal compensation device. (11) Wheel counter. (12) Self diagnosis functions. (13) Machine light. (14) Spindle load meter. (15) Leveling blocks and foundation bolts. (16) RS232C interface. (17) Interactive automatic programming. (18) Cycle-end indicating lamp. (19) Automatic calculation of cutting conditions. (20) Standard tool set. (21) All servo motors are brushless, maintenance-free AC type drives. (22) Complete electrical equipment for 3-phase, 60 hertz, 230 volts. (23) CNC control, Fanuc 16MA. (24) Isolation transformer 216V - 480V range. (Other voltages must be quoted separately). MITSUBISHI ZGI000CNC GRINDING MACHINE (prices when new): BASE MACHINE $1,400,000 1. Automatic closing coolant guard door $6,300 Yes 2. Automatic tooth orientation device $20,400 yes 3. Grinding wheel truing/dressing device $67,000 yes 4. Circuit breaker with ground fault interrupter circuit $1,900 yes 5. Power on/off key switch $900 yes 6. Double palm start buttons $900 yes 7. Wheel arbor $5,300 yes 8. Work arbor (solid) $14,400 ?/yes 9. Diamond rotary dresser (1 set) $9,000 ?/yes 10. Hydraulic work clamping device $20,000 ?/yes TOTAL $1,546,100

DESCRIPTION :For Sale… Mitsubishi CNC Gear Grinder 1000mm, like new, loaded w/options, Fanuc-16M controls...but missing part programming software, Great candidate/opportunity for re-control or repair, Mitsubishi Gear grinding and Hobbing parts, Most are new in the box, 6-servo motors, 5-servo Drives, 5-manual rests, 4-wheel flange5.5", Cylinder, 2 balancing arbors, spindle, 2 main metal, 2 bushings, 9 change gears, 23-gear hob arbors Year 1996 but only used for a few months then stored.

NILES Backing Off Lathe, very nice machine - FCA PRICE DH250/4

MACHINE REF :13470

Machines For Sale — . Lathe, Backing Off

MAKE :NILES Backing Off Lathe, very nice machine - FCA PRICE

MODEL :DH250/4

CONTROLLER :conventional

MEKA Sand casting installation With manipulators and 13 CNC machined moulds - visible working

MACHINE REF :6975

Machines For Sale — . Casting & Foundry

MAKE :MEKA Sand casting installation

MODEL :With manipulators and 13 CNC machined moulds - visible working

SPECIFICATION :Complete with two manipulators 13 CNC machined moulds Can be seen under power

DESCRIPTION :Hydraulic and pneumatic twin moulding machine MEKA (swiss) After compacting the green sand, the machine rotates and leaves the mould halves on the press plates from where they are taken away by the manipulator. With manipulator for empty chassis And manipulator for ready moulds. This manipulator is also used to bring mould halves together. Mould size: 440x 720 x 240/240 Originally the machine was purchased by stork pumps to cast iron. It has been used consistently for aluminium. The machine was designed to produce up to 400 moulds a day.(8 hours) Hydraulic unit 5.5 Kw

HITACHI 1350mm x 3mm Stainless cut to length line (1993)

MACHINE REF :16254

Machines For Sale — . Sheet Metal, Cut To Length

MAKE :HITACHI

MODEL :1350mm x 3mm Stainless cut to length line

YEAR OF MANUFACTURE :1993

SPECIFICATION :PRICE ON REQUEST FURTHER IMAGES ON REQUEST 1350 mm x 3mm Stainless Steel Cut to Length Line (Flying type) Make: Hitachi Year: 1993 Material: stainless steel, surface treated steel

DESCRIPTION :Thickness: 0.3–3 mm (as of stainless steel) Width: 500-1350 mm Trim: 5-25 mm on one side (more than twice the plate thickness) Material coil: internal diameter 508 mm, external diameter 600–1800 mm weight maximum 15 tons Width accuracy: 500–1350 mm plus or minus 0.2 mm (when side trimming) Product length: 400–6000 mm Plus/minus 0.3 mm 6-leveler (6-hi) leveler 2 types Tension: 45 to 50 kg/mm2 Yield point: 28 kg/mm2 Cutting method: Cut while running (flying), numerically controlled rocking type flying shears (Cutting speed) 20–40/80 m/min Speed 2-speed change type 0.3 to 1.2 mm: 20 to 80 m/min 0.21–3 mm: 20–40 m/min Slow operation: 0.8 m/min Conveyor speed: 20~120m/min Cut count: up to 150 cuts/min (Product piling) Plate width: 500–1350 mm No1 piler: 400 to 3100 mm (also used as a reject piler) No2 piler: 400–6100 mm Load height: up to 600mm Load weight: up to 4 tons Line direction: From right to left on control panel Line: Approximately 13 m x 49.050 m (Major facilities) Coil skid Coil car Pay off reel and a paper winder Coil opener Rough Leveler Shear No. 1 Looper Guide Side guide and pinch roller Side trimmer Scrap winder x2 No.1 Finisher Leveler (6-hi) No2 Finisher Leveler (6-hi) No 2 Looper Guide Measuring roller, feed roller and paper-off reel Shear Conveyor Cart No1/No2 piler type Hydraulic unit: Type Valve stand type (Coil skid) V-type fixed skid Coil maintenance: 1 coil Coil weight: up to 15 tonnes Coil diameter: 600 to 1800 mm urethane rubber (Coil Car) Cradle roller type Hydraulic boost Electricity transfer driving type Two guide lots hydraulic cylinder elevating type (payoff reel and paper winder) Overhang, single-mant 4-segment type Paper reel motor: DC 5.5KW 400/1600 RPM, attached to brake Paper winder: cone type, (motor DC 1.5KW, 1750 RPM) (Coil Opener) Knife edge method (Rough Leveler) 2-stage (2hi) 5-body roller leveler Pinch rollers: 160 mm × 1450 mm 2 pieces, The upper part of the pinch roller is hydraulic cylinder press-down, and the lower roller is fixed 5 workload rollers 130mm x 1450mm The upper roller of the workload roller is electrically pressed, and the lower roller is fixed 0–40/80 m/min Two-stage change 0.3 to 1.6 mmt: 80 m/min 1.7 to 1.6 mmt: 40 m/min Motor: DC 18.5 KW, 1750 RPM, Brake Attachment Pressing motor: 2 1.5KW 100RPMs with brakes (Shear) Hydraulic up cut shear Knife size: 25 mm thickness × 150 mm width × 1450 mm length (No. 1 Looper Guide) Table lift Hydraulic cylinder operation method Loop: Light Volume Control Method Roller: 70 mm diameter × 1450 mm × 6 bonds, rubber lining roller (Side guide and pinch roller) Vertical Free Roller Electrically switched type Side guide roller: 90 mm diameter × 150 mm length × 6 bones Pinch Roller: 2nd Stage (2hi) Roller: 160 mm diameter × 1450 mm length × 2 bones Upper roller: pneumatic cylinder pressure free roller Lower Roller: Fixed Drive Roller (Side trimmer) Overhang Drive Cut 0–40/80 m/min 2-stage change type 0.3 to 1.6 mmt: 80 m/min 1.7 to 1.6 mmt: 40 m/min Cutter diameter: 320 mm / 190 mm internal diameter × 20 mm thickness Roller: 320 mm external diameter × 19 mm internal diameter × 20 mm thickness Motor: DC 5.5KW 1750RPM (Scrap winder) Two machines Link Pin Gauge Type (Hydraulic Cylinder Opening and Closing Type) Motor: 2 DC 2.2KW 1450 RPM (No1 Finisher Leveler) 6-level (6-hi) 17 leveler Thickness: 1.21–3.0 mm Speed: 6 to 40/80 m/min Thickness 0.3–1.2 mm 6–80 m/min Thickness 1.21–3 mm 6–40 m/min Pinch roller: 180 mm × 1750 mm × 2 bones The upper roll is a pneumatic cylinder. The lower roll is fixed Rubber lining drive roller Work roll: 60mm x 1750mm x 17e 8 for the upper roll, 9 for the lower roll Plated abrasive roller Medium roller: 50 mm × 1750 mm × 19 pieces 9 for the upper roll, 10 for the bottom roll Backup Roller: 88 mm Diameter x 50 mm Length x 7 rows Pressing Method: Lower Roller Parallel Pressing Pressing speed: 0.25 mm/sec Pressurization: plus or minus 5 mm Motor: DC 55KW 1750 RPM Brake Attachment (No2 Finisher Leveler) 6-level (6-hi) 17 leveler Plate thickness: 0.3–1.2 mm Speed: 5 to 80 m/min Pinch roller: 180 mm × 1750 mm × 2 bones The upper roll is a pneumatic cylinder. The lower roll is fixed Rubber lining drive roller Work roll: 35mm x 1750mm x 17bon 8 for the upper roll, 9 for the lower roll Plated abrasive roller Medium Roller: 32 mm × 1750 mm × 19 pieces 9 for the upper roll, 10 for the bottom roll Backup Roller: 99 mm Diameter x 50 mm Length x 7 rows Roller bearing type Pressing Method: Lower Roller Parallel Pressing Pressing speed: 0.25 mm/sec Pressurization: plus or minus 5 mm Motor: DC 35KW 1750RPM Brake Attachment (No. 2 Looper Guide) Table lift Hydraulic cylinder operation method Loop: How to control the amount of light (amount of light) Roller: 70 mm diameter × 1450 mm × 6 bonds, rubber lining roller (Measuring roll/feed roller/paper vinyl payoff reel) Measuring roller: The upper roll is pneumatic pressing, the lower roll is fixed, the pressing amount is 30 mm Feed roller: Upper roll is pneumatic cylinder press, lower roll is fixed, press load is 40 mm Motor: DC 2.2KW 1750RPM (Shear) Fluctuating Flying shear 0.3~3mm Speed: 2 groups of 20–40/80 m/min Thickness 0.3–1.6 mm 80 m/min Tlate thickness 1.6–3 mm 40 m/min Cut count: up to 150 cuts/min Cutting length: 400–6000 mm Electric up CUT shear Cut up and down knife die via motor, reducer, pinion stand crankshaft Knife: 20 mmt × 80 mm × 1400 mm × 1 set The top knife is a straight knife, and the bottom is a V-lock knife Adjustment: Wedge Motor: DC 75KW 550RPM (conveyor) Belt conveyor type Belt width: 1200 mm Conveyor length: 3800 mm Motor DC 5.5KW 1450RPM Brake Attachment (No. 1 No. 2 piler) No1 piler: Combined use of reject truck, air blower Combined use of side conveyor No2 piler: Combined suction conveyor and air blower Loading height: 600 mm Lift: Hydraulic lift volume 650 mm Motor: 4 1.5KW 150RPM units for side guide end stoppers 2.2 KW 1500RPM for lifters 1.5KW for cart 7.5KW for blower (Hydraulic device) 70 kg/cm2 × 100 L/min Pen pump Motor: DC 18.5 KW 1000 RPM (Supply power) AC400 V,50 Hertz 3 Phase / AC200V, 50 Hertz 3 Phase (Control power) AC 200V, 50 Hz Single Phase (Compressed air) Compressed air required: 5 kg/cm2

ERFURT C-Frame Hydraulic Press - NEVER USED PYE 63S/1M, capacity 63 t, lower ejector

MACHINE REF :12539

Machines For Sale — . Press, Hydraulic

MAKE :ERFURT C-Frame Hydraulic Press - NEVER USED

MODEL :PYE 63S/1M, capacity 63 t, lower ejector

CONTROLLER :conventional

SCHAUBLIN Centre Lathe - FCA PRICE 150, capacity DxL 340x600 mm

MACHINE REF :15503

Machines For Sale — . Lathe, Conventional

MAKE :SCHAUBLIN Centre Lathe - FCA PRICE

MODEL :150, capacity DxL 340x600 mm
