KOLOMNA Heavy Duty Gear Hobber 5A342 - 2m x module 25 - refurbished 2015, excellent condition
MACHINE REF :13319
Machines For Sale — . Gear, Hobber
MAKE :KOLOMNA Heavy Duty Gear Hobber
MODEL :5A342 - 2m x module 25 - refurbished 2015, excellent condition
SPECIFICATION :Year of construction: 1970 Technical data: Gear hobbing machine model 5A342 Manufacturer: KOLOMNA (Russia) Year of manufacture: 1970 Main technical data: Max gear diameter : 2000 mm Max module : 25 Max hobbing length of 500 mm Table diameter : 1800 mm Maximum table load : 10 t Main motor power : 14 kW Overall dimensions(LxWxH) : 6910x2990x3462 mm Weight of the machine : 31800 kg
DESCRIPTION :Accesories: Set of change gears ab. 80pcs; Aditional hobbing head tooth by tooth One arbor 2pcs. supports The machine was refurbished. Mechanical revision. Gears checked. New painting. The electrical equipment is new one. The machine is in working condition.
HYUNDAI WIA CNC Lathe L400LC 630mm x 2100mm (2014) (2 off machines available) (2014)
MACHINE REF :15307
Machines For Sale — . Lathe, CNC Fixed Head >=2m b/c
MAKE :HYUNDAI WIA CNC Lathe
MODEL :L400LC 630mm x 2100mm (2014) (2 off machines available)
YEAR OF MANUFACTURE :2014
CONTROLLER :Fanuc
SPECIFICATION :Maximum turning Dia 630mm Turning Length - 2100 mm Year of Manufacture :2014 Spindle speed 2000rpm Spindle power 37/30Kw Standard chuck with special jaws - 15 inch Machines in full working condition
DESCRIPTION :2 off available. Price per machine, EXW basis Images of specific machines and videos on request.
AWEA Vertical Machining Centre FCA PRICE BM-1020, table 1120x600 mm, XYZ 1020x600x600 mm, 24x BT40 ATC, 12000 rpm (2006)
MACHINE REF :13601
Machines For Sale — . Machining Centre, Vertical
MAKE :AWEA Vertical Machining Centre FCA PRICE
MODEL :BM-1020, table 1120x600 mm, XYZ 1020x600x600 mm, 24x BT40 ATC, 12000 rpm
YEAR OF MANUFACTURE :2006
CONTROLLER :FANUC 18 iMB
TRUMPF CNC Laser TRUMATIC L2530 (1999) 3kw laser 2.5m x 1.25m, CE marked (1999)
MACHINE REF :12495
Machines For Sale — . Sheet Metal & Plate, Laser Cutter
MAKE :TRUMPF CNC Laser
MODEL :TRUMATIC L2530 (1999) 3kw laser 2.5m x 1.25m, CE marked
YEAR OF MANUFACTURE :1999
DESCRIPTION :fob port price machine not under power but good working condition
ROSSI MONZA Centreless Grinders 300 (4 off lot - price for lot) in good condition
MACHINE REF :9546
Machines For Sale — . Grinder, Centreless
MAKE :ROSSI MONZA Centreless Grinders
MODEL :300 (4 off lot - price for lot) in good condition
SPECIFICATION :for plunge or through-feed grinding
DESCRIPTION :Individual price 7500 eur per machine ages vary between 1980 and 1987
ORENBURG Hydraulic Press, in very good working condition, revised P6334A, capacity 250 j, table 630x1000 mm, shut 800 mm
MACHINE REF :16160
Machines For Sale — . Press, Hydraulic
MAKE :ORENBURG Hydraulic Press, in very good working condition, revised
MODEL :P6334A, capacity 250 j, table 630x1000 mm, shut 800 mm
SPECIFICATION :Nominal effort 2500 kN, Ram stroke 500 mm, Shut height 800 mm, Table size 630x1000 mm, Main motor power 18,5 kW, Overall dimensions LxWxH 1250x2170x3150 mm, Weight 10940 kg
DESCRIPTION :Press is in very good working condition; all sealings replaced, piston is with new crome coating.
Z. BAVELLONI ALPA 103 CNC Glass Cutting Machine (1995)
MACHINE REF :11608
Machines For Sale — . Glass Machinery
MAKE :Z. BAVELLONI
MODEL :ALPA 103 CNC Glass Cutting Machine
YEAR OF MANUFACTURE :1995
SPECIFICATION :Hello, For sale glass cutting CNC machine tool Z. BAVELLONI ALPA 103 of the 1995 year.
DESCRIPTION :Please contact us for further information - price is negotiable.
RYAZAN Heavy Duty Centre Lathe (1992), top condition 1M63BF101, capacity DxL 630x3000 mm (1992)
MACHINE REF :16147
Machines For Sale — . Lathe, Conventional >=2m b/c
MAKE :RYAZAN Heavy Duty Centre Lathe (1992), top condition
MODEL :1M63BF101, capacity DxL 630x3000 mm
YEAR OF MANUFACTURE :1992
CONTROLLER :conventional
HYUNDAI CNC Lathe HIT 18S (7 off) ages 2002-2006 tailstocks, siemens
MACHINE REF :15204
Machines For Sale — . Lathe, CNC Fixed Head
MAKE :HYUNDAI CNC Lathe
MODEL :HIT 18S (7 off) ages 2002-2006 tailstocks, siemens
CONTROLLER :SIEMENS
DESCRIPTION :Prices on request (vary with ages) More images on request.
CHIRON Vertical Machining Centre FZ 22 L (1989) - 2.2m x 400mm x 425mm - Siemens 840 - SK40 (1989)
MACHINE REF :5719
Machines For Sale — . Machining Centre, Vertical
MAKE :CHIRON Vertical Machining Centre
MODEL :FZ 22 L (1989) - 2.2m x 400mm x 425mm - Siemens 840 - SK40
YEAR OF MANUFACTURE :1989
CONTROLLER :Siemens 840
SPECIFICATION :Siemens 840, xyz=2200/400/425 mm, 36 poss., SK 40, RPM 6000, 27 kW
LEADWELL Vertical Machining Centre, working condition, VIDEO MCV-OP, table 650x350 mm, XYZ 510x360x410 mm, spindle 6000 rpm, 16x ATC (1994)
MACHINE REF :16176
Machines For Sale — . Machining Centre, Vertical
MAKE :LEADWELL Vertical Machining Centre, working condition, VIDEO
MODEL :MCV-OP, table 650x350 mm, XYZ 510x360x410 mm, spindle 6000 rpm, 16x ATC
YEAR OF MANUFACTURE :1994
CONTROLLER :FANUC 0-M
SACK & KIESSELBACH Hydraulic Press, working condition, under power - VIDEO Capacity 1250 MPa, specification on pictures (1974)
MACHINE REF :15695
Machines For Sale — . Press, Hydraulic
MAKE :SACK & KIESSELBACH Hydraulic Press, working condition, under power - VIDEO
MODEL :Capacity 1250 MPa, specification on pictures
YEAR OF MANUFACTURE :1974
CONTROLLER :conventional
DMG 5 axis machining centre DMU 50 eVolution (2000) (2000)
MACHINE REF :9364
Machines For Sale — . Machining Centre, 5-Axis Vertical
MAKE :DMG 5 axis machining centre
MODEL :DMU 50 eVolution (2000)
YEAR OF MANUFACTURE :2000
SPECIFICATION :(1) used 2000 DECKEL MAHO DMU50 eVolution 5-Axis Vertical Machining Center: Made in Seebach, Germany -Clamp once, machine 5-Sides- Table on machine swivels 0-180 degrees and rotates 360 degrees which allows for 5-Sided 5-Axis machining with one work piece clamping. Heidenhain Millplus CNC control -WORK AREA- Traverse path X (longitudinal).......................... 19.7" (500 mm) Traverse path Y (across)................................ 16.5" (420 mm) Traverse path Z (vertical)................................ 15" (380 mm) -MAIN DRIVE- AC-motor spindle drive power 100% DC................... 33.5 HP (25 kW) AC-motor spindle drive power 40% DC.................... 46.9 HP (35 kW) Spindle speed............................................ 20-18,000 rpm Spindle taper................................................... CAT 40 Number of gear steps.............................................. None Max Spindle Torque................................ 95.9 Ft/Lbs (130 Nm) Spindle Bearing Diameter................................. 3.15" (80 mm) -FEED DRIVES- Rapid traverse linear axes X/Y/Z................ 1,968.5 ipm (50 m/min) Feed Range linear axes X/Y/Z...................... 787.4 ipm (20 m/min) -TOOL MAGAZINE- Storage pockets........................................... 32 positions Maximum tool weight................................... 13.22 lbs (6 kg) Maximum tool diameter without vacant places.............. 3.15" (80 mm) Maximum tool diameter with vacant places................ 4.13" (105 mm) Maximum tool length.................................... 11.02" (280 mm) Chip to chip time.............................. Approximately 6 seconds -FLOOD COOLANT- Amount of coolant................................. 52.8 gallons (200 l) Flow rate............................. 5.28 gallon/minute (20 l/minute) -MEASURING SYSTEM- Direct, Heidenhain glass scales, resolution 0.00004" for X/Y/Z Heidenhain direct angle encoders for B & C Axes -NC SWIVEL ROTARY TABLE- Clamping surface.......................... 19.7" x 15.0" (500 x 380 mm) Swivel range 5th (swivel) B-axis......................... 0-180 degrees Rotation range 4th (rotary) C-axis 0-360 degrees (continous, full 4th) Rapid traverse, (swivel) B-axis................................. 26 rpm Rapid traverse, (rotary) C-axis................................. 33 rpm Maximum table load.................................... 441 lbs (200 kg) Table measuring system....... Direct path measuring system in both axes Table cooling....... Drive cooling for B and C axis with heat exchanger Table swivel time, horizontal/vertical....... Approximately 1.5 seconds
DESCRIPTION :-EQUIPPED WITH- Transformer Chip Pan with coolant pump Preparation for chip conveyor Preparation including plumbing and electrics for Coolant Thru The Spindle Price includes loading
ECHEA (Spain) Heavy Lathe BRN 1000-C - 2.1m x 10m - 40ton load - excellent
MACHINE REF :9084
Machines For Sale — . Lathe, Conventional >=2m b/c
MAKE :ECHEA (Spain) Heavy Lathe
MODEL :BRN 1000-C - 2.1m x 10m - 40ton load - excellent
SPECIFICATION :Heavy Duty Lathe ECHEA BRN 1000-C Type: BRN 1000-C Machine modernization in: 2006 Made in: Spain tailstock, steady rest, DRO ocular read out in 2 axis Heidenhain Turning diameter over bed: 2 .100 mm Turning diameter over support: 1 920 mm Turning length: 10 000 mm Spindle passage: 150 mm Max weight on table: 40 000 kg chuck diameter- 1,600 mm
ESSA High Speed Mechanical Press, working condition, under power - VIDEO BH15TO, capacity 15 t, table 300x300 mm (1972)
MACHINE REF :15851
Machines For Sale — . Press, Mechanical
MAKE :ESSA High Speed Mechanical Press, working condition, under power - VIDEO
MODEL :BH15TO, capacity 15 t, table 300x300 mm
YEAR OF MANUFACTURE :1972
CONTROLLER :conventional
WMW Niles Gear Hobber ZFWZ 5000 - 5m x 50modul
MACHINE REF :16163
Machines For Sale — . Gear, Hobber
MAKE :WMW Niles Gear Hobber
MODEL :ZFWZ 5000 - 5m x 50modul
SPECIFICATION :- max. wheel diameter: 5000 mm - gear width: 1500 mm - max. module: 50 (40) - max. helix angle: 45 ° / deg - table diameter: 4000 mm - table bore diameter: 800 mm - table load: 60 t - raised turning speeds: 8 - 56 rpm Feeds - axial: 0.25 - 8 mm / min - radial: 0.12 - 4 mm / min - tangential: 0.12 - 4 mm / min - weight of the machine approx.: 140 t - dimensions of the machine approx.: 12.0 x 9.0 x 6.75 m
INDEX CNC turning centre ABC Speedline (1995)
MACHINE REF :13440
Machines For Sale — . Lathe, CNC Fixed Head
MAKE :INDEX CNC turning centre
MODEL :ABC Speedline
YEAR OF MANUFACTURE :1995
SPECIFICATION :Index ABC Speedline CNC turning centre New 1995 Full 42mm bar capacity Sub spindle Polygon attachment IEMCA CNC BOSS 542 magazine bar loader
DESCRIPTION :serial number 400151 NB: There are no tools included with this machine video on request
TRUMPF Laser Cutter (2008), 48614/22791 hrs TRUMATIC L5030, power 7kW, XYZ 3000x1500x150 mm
MACHINE REF :13811
Machines For Sale — . Sheet Metal & Plate, Laser Cutter
MAKE :TRUMPF Laser Cutter (2008), 48614/22791 hrs
MODEL :TRUMATIC L5030, power 7kW, XYZ 3000x1500x150 mm
CONTROLLER :CNC
SPECIFICATION :Laser power 7kW (diamond output mirror), Work area: -X: 3000 mm. -Y: 1500 mm. -Z: 150 mm. Two available heads: High speed (up to 3 mm) and standard.
DESCRIPTION :Machine working hours: 22791 Resonator working hours: 48614 Machine is disassembled and ready for loading on trucks/containers. It has been recently disassembled by TRUMPF official service. Video of machine working available on request.
NILES Gear Grinder, working condition, visible under power - EXLOADED ZSTZ 800, gear dia 80-800 mm, module 2-14, number of teeth 6-140
MACHINE REF :15108
Machines For Sale — . Gear, Grinder
MAKE :NILES Gear Grinder, working condition, visible under power - EXLOADED
MODEL :ZSTZ 800, gear dia 80-800 mm, module 2-14, number of teeth 6-140
CONTROLLER :conventional
SPECIFICATION :MORE PICTURES AVAILABLE ON REQUEST.
UNION Table Type Horizontal Borer (1989), in excellent condition - FOB PRICE BFT 90/3, spindle 90 mm, tailstock, facing head, tooling (1989)
MACHINE REF :11196
Machines For Sale — . Borer, Horizontal Table
MAKE :UNION Table Type Horizontal Borer (1989), in excellent condition - FOB PRICE
MODEL :BFT 90/3, spindle 90 mm, tailstock, facing head, tooling
YEAR OF MANUFACTURE :1989
CONTROLLER :conventional
CINCINNATI CNC Laser (2006); 21,000 Beam On Hours CL7, power 3300 W, 5 X 10 Shuttle Tables (2006)
MACHINE REF :9895
Machines For Sale — . Sheet Metal & Plate, Laser Cutter
MAKE :CINCINNATI CNC Laser (2006); 21,000 Beam On Hours
MODEL :CL7, power 3300 W, 5 X 10 Shuttle Tables
YEAR OF MANUFACTURE :2006
CONTROLLER :CINCINNATI
SPECIFICATION :3300 Watt Rating, 5 X 10 Shuttle Tables, New Resonator (2014), New X-Axis Ball Screw (2014), New Linear Bearing (2014), 21,000 Beam On Hours, 58,000 Control On Hours, Cincinnati CNC Controls
DESCRIPTION :Complete Machine With All Electrics & Dust Collector Per Enclosed Photos. Excellent Condition, Inspect In Plant Under Power Running Parts.
