Showing 2713–2724 of 8186 results
Quick View
,
KOLOMNA Ram Type VTL 1540, turning capacity DxH 4000×2000 mm (1965)

KOLOMNA Ram Type VTL 1540, turning capacity DxH 4000x2000 mm (1965)



MACHINE REF :4265

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1540, turning capacity DxH 4000x2000 mm

YEAR OF MANUFACTURE :1965

CONTROLLER :conventional

SPECIFICATION :Maximum workpiece diameter 4000 mm, Maximum workpiece height 2000 mm, Maximum workpiece weight 63 t, Faceplate diameter 4000 mm Faceplate speeds range 0,52-48,7 rpm Main motor power 125 kW Overall dimensions, LxWxH 5900x10100x7200 mm Weight of the machine 105 t

FURTHER SPECIFICATION :Maximum workpiece diameter 4000 mm Maximum workpiece height 2000 mm Maximum workpiece weight 63000kg Faceplate diameter 4000 mm Faceplate speeds range 0,52-48,7 rpm Maximum faceplate torque 160 kNm Maximum cross beam vertical travel 1870 mm Maximum vertical rams vertical travel 1250 Maximum vertical rams horizontal travel 2300 Maximum vertical supports turning angle +30/-15 degree Maximum vertical supports vertical and horizontal feeds range 0.059-470mm/min Vertical rams and supports fast travel speed 2715 mm/min Cross beam fast travel speed 2715 mm/min Main motor power 125 kW Overall dimensions, LxWxH 5900x10100x7200 mm Height over the floor 6000 mm Weight of the machine 105000 kg

DESCRIPTION :price should be understood FOB Ukraine.
Quick View
,
KOLOMNA Ram Type VTL 1540, turning capacity DxL 4000×2000 mm (1965)

KOLOMNA Ram Type VTL 1540, turning capacity DxL 4000x2000 mm (1965)



MACHINE REF :3018

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1540, turning capacity DxL 4000x2000 mm

YEAR OF MANUFACTURE :1965

CONTROLLER :conventional

SPECIFICATION :Maximum workpiece diameter 4000 mm Maximum workpiece height 2000 mm Maximum workpiece weight 63000kg Faceplate diameter 4000 mm Faceplate speeds range 0,52-48,7 rpm Maximum faceplate torque 160 kNm Maximum cross beam vertical travel 1870 mm Maximum vertical rams vertical travel 1250 Maximum vertical rams horizontal travel 2300 Maximum vertical supports turning angle +30/-15 degree Maximum vertical supports vertical and horizontal feeds range 0.059-470mm/min Vertical rams and supports fast travel speed 2715 mm/min Cross beam fast travel speed 2715 mm/min Main motor power 125 kW Overall dimensions, LxWxH 5900x10100x7200 mm Height over the floor 6000 mm Weight of the machine 105000 kg
Quick View
,
KOLOMNA Ram Type VTL 1540F1, capacity DxH 4000×2000

KOLOMNA Ram Type VTL 1540F1, capacity DxH 4000x2000



MACHINE REF :4292

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1540F1, capacity DxH 4000x2000

SPECIFICATION :Maximum workpiece diameter 4000 mm Maximum workpiece height 2000 mm Maximum workpiece weight 63000kg Faceplate diameter 4000 mm Faceplate speeds range 0,52-48,7 rpm Main motor power 125 kW Overall dimensions, LxWxH 5900x10100x7200 mm Weight of the machine 105000 kg

FURTHER SPECIFICATION :Maximum workpiece diameter 4000 mm Maximum workpiece height 2000 mm Maximum workpiece weight 63000kg Faceplate diameter 4000 mm Faceplate speeds range 0,52-48,7 rpm Maximum faceplate torque 160 kNm Maximum cross beam vertical travel 1870 mm Maximum vertical rams vertical travel 1250 Maximum vertical rams horizontal travel 2300 Maximum vertical supports turning angle +30/-15 degree Maximum vertical supports vertical and horizontal feeds range 0.059-470mm/min Vertical rams and supports fast travel speed 2715 mm/min Cross beam fast travel speed 2715 mm/min Main motor power 125 kW Overall dimensions, LxWxH 5900x10100x7200 mm Height over the floor 6000 mm Weight of the machine 105000 kg

DESCRIPTION :Price should be understood Ex-loaded on means of transport.
Quick View
,
KOLOMNA Ram Type VTL 1540F1, turning capacity DxH 4000×2000 mm

KOLOMNA Ram Type VTL 1540F1, turning capacity DxH 4000x2000 mm



MACHINE REF :4252

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1540F1, turning capacity DxH 4000x2000 mm

CONTROLLER :conventional

SPECIFICATION :Maximum workpiece diameter 4000 mm Maximum workpiece height 2000 mm Maximum workpiece weight 63000kg Faceplate diameter 4000 mm Faceplate speeds range 0,52-48,7 rpm Main motor power 125 kW Overall dimensions, LxWxH 5900x10100x7200 mm Height over the floor 6000 mm Weight of the machine 105000 kg

FURTHER SPECIFICATION :Maximum workpiece diameter 4000 mm Maximum workpiece height 2000 mm Maximum workpiece weight 63000kg Faceplate diameter 4000 mm Faceplate speeds range 0,52-48,7 rpm Maximum faceplate torque 160 kNm Maximum cross beam vertical travel 1870 mm Maximum vertical rams vertical travel 1250 Maximum vertical rams horizontal travel 2300 Maximum vertical supports turning angle +30/-15 degree Maximum vertical supports vertical and horizontal feeds range 0.059-470mm/min Vertical rams and supports fast travel speed 2715 mm/min Cross beam fast travel speed 2715 mm/min Main motor power 125 kW Overall dimensions, LxWxH 5900x10100x7200 mm Height over the floor 6000 mm Weight of the machine 105000 kg
Quick View
,
KOLOMNA Ram Type VTL 1540F1, turning capacity DxL 4000×2000 mm (1977)

KOLOMNA Ram Type VTL 1540F1, turning capacity DxL 4000x2000 mm (1977)



MACHINE REF :3848

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1540F1, turning capacity DxL 4000x2000 mm

YEAR OF MANUFACTURE :1977

CONTROLLER :DRO Russian type

SPECIFICATION :Max workpiece dia 4000 mm, Max workpiece height 2000 mm, Max workpiece weight 63 t, Faceplate diameter 4000 mm, Machine overall dimensions 5900x10100x7200 mm, Machine weight 100 t
Quick View
,
KOLOMNA Ram Type VTL 1540F1, turning capacity DxL 4000×2000 mm (1978)

KOLOMNA Ram Type VTL 1540F1, turning capacity DxL 4000x2000 mm (1978)



MACHINE REF :3283

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1540F1, turning capacity DxL 4000x2000 mm

YEAR OF MANUFACTURE :1978

CONTROLLER :conventional

SPECIFICATION :Max workpiece diameter 4000 mm Max workpiece height 2000 mm Max workpiece weight 50,0 t Faceplate diameter 4000 mm Faceplate speeds range 0,52-48,7 rpm Main motor power 63 kW Overall dimensions LxWxH 5900x10100x7200 mm Height over the floor 6000 mm Mass of the machine with electrical equipment 100 t

DESCRIPTION :Price should be understood FCA location.
Quick View
,
KOLOMNA Ram Type VTL 1540T, capacity DxH 4000×2500 mm, max workpiece weight 100 t (1969)

KOLOMNA Ram Type VTL 1540T, capacity DxH 4000x2500 mm, max workpiece weight 100 t (1969)



MACHINE REF :4022

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1540T, capacity DxH 4000x2500 mm, max workpiece weight 100 t

YEAR OF MANUFACTURE :1969

CONTROLLER :conventional

SPECIFICATION :Max workpiece diameter 4000 mm, Max workpiece height 2500 mm, Max workpiece weight 100 t, Faceplate diameter 4000 mm, Faceplate speeds range 0,46-42,50 rpm, Main motor power 125 kW, Overall dimensions LxWxH 10410x6100x8400 mm, Weight 134,2 t
Quick View
,
KOLOMNA Ram Type VTL 1540T, capacity DxL 4000×2500, workpiece weight 100 t (1969)

KOLOMNA Ram Type VTL 1540T, capacity DxL 4000x2500, workpiece weight 100 t (1969)



MACHINE REF :4868

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1540T, capacity DxL 4000x2500, workpiece weight 100 t

YEAR OF MANUFACTURE :1969

CONTROLLER :conventional

SPECIFICATION :Maximum workpiece diameter 4000 mm, Maximum workpiece height 2500 mm, Maximum workpiece weight 100 t, Faceplate diameter 4000 mm, Faceplate speeds range 0,46-43 rpm, Main motor power 180 kW, Overall dimensions (LxWxH) 6100x10400x8400 mm, Weight 134200 kg
Quick View
,
KOLOMNA Ram Type VTL 1540T, turning capacity DxL 4000×2500 mm, workpiece weight 100 t

KOLOMNA Ram Type VTL 1540T, turning capacity DxL 4000x2500 mm, workpiece weight 100 t



MACHINE REF :3847

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1540T, turning capacity DxL 4000x2500 mm, workpiece weight 100 t

CONTROLLER :conventional

SPECIFICATION :Max workpiece dia 4000 mm, Max workpiece height 2500 mm, Max workpiece weight 100 tons, Faceplate dia 4000 mm, Overall dimensions 6100 x 10400 x 8400 mm, Machine weight 134 t
Quick View
,
KOLOMNA Ram Type VTL 1550, capacity DxH 5000×2500 mm (1977)

KOLOMNA Ram Type VTL 1550, capacity DxH 5000x2500 mm (1977)



MACHINE REF :11296

Machines For Sale — . Borer, Vertical/VTL Turret

MAKE :KOLOMNA Ram Type VTL

MODEL :1550, capacity DxH 5000x2500 mm

YEAR OF MANUFACTURE :1977

CONTROLLER :conventional

SPECIFICATION :Maximum workpiece diameter 5000 mm, Maximum workpiece height 2500 mm, Maximum workpiece weight 100 000 kg, Faceplate diameter (not dismountable) 4500 mm, Faceplate speeds range 0,34-31 rpm, Main motor power 180 kW, Overall dimensions (LxWxH) 6600x11400x8400 mm, Weight 140500 kg
Quick View
,
KOLOMNA Ram Type VTL 1550, capacity DxL 5000×2500 mm

KOLOMNA Ram Type VTL 1550, capacity DxL 5000x2500 mm



MACHINE REF :4833

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1550, capacity DxL 5000x2500 mm

CONTROLLER :conventional

SPECIFICATION :Max workpiece diameter 5000 mm, Max workpiece heigh 2500 mm, Max workpiece weight 100 t, Faceplate diameter (nonseparable) 4500 mm, Faceplate speeds range 0,34-31 rpm, Main motor power 180 kW Machine overall dimensions LxWxH 6600x11400x8400 mm, Machine weight 140,5 t

DESCRIPTION :In good, working condition. Price should be understood CIF any seaport.
Quick View
,
KOLOMNA Ram Type VTL 1550, turning capacity DxH 5500×2500 mm (1968)

KOLOMNA Ram Type VTL 1550, turning capacity DxH 5500x2500 mm (1968)



MACHINE REF :5222

Machines For Sale — . Borer, Vertical/VTL Ram Type

MAKE :KOLOMNA Ram Type VTL

MODEL :1550, turning capacity DxH 5500x2500 mm

YEAR OF MANUFACTURE :1968

CONTROLLER :conventional

SPECIFICATION :Chuck diameter, mm 4 500 Work piece maximum weight, kg 100 000 Work piece maximum height, mm 2 500 Max. work piece diameter, mm 5 000 Chuck speed, rpm 0,34 ... 31 Main electric motor power, kW 125 Machine overall dimensions, mm 6600 x 11400 x 8400 Machine weight, kg 140 500

DESCRIPTION :Machine is in ideal condition, Almost not used!
