Showing 3817–3828 of 8624 results
Quick View
,
NILES WMW Gear Hobber ZFWZ 2000/3 Diameter max 2100mm x 710mm x 22 module with tailstock

NILES WMW Gear Hobber ZFWZ 2000/3 Diameter max 2100mm x 710mm x 22 module with tailstock



MACHINE REF :13567

Machines For Sale — . Gear, Hobber

MAKE :NILES WMW Gear Hobber

MODEL :ZFWZ 2000/3 Diameter max 2100mm x 710mm x 22 module with tailstock

SPECIFICATION :max. wheel ø - 2100 mm gear width - 710 mm max. module - 22 hob - ø and width - 300x330 mm table ø - 1800 mm table load 15000 kg min. workpiece ø - 600 mm min. number of teeth - 10 shifting - 850 mm table bore ø - 700 mm max. angle of teeth - 45° weight of the machine ca. 40 t

FURTHER SPECIFICATION :Accessories: tailstock, hobbing head, change gears, arbors FCA, loaded in trucks/containers.
Quick View
,
Niles WMW ZSTZ 10H (1985) 1250mm x 25 modul – CIF any port

Niles WMW ZSTZ 10H (1985) 1250mm x 25 modul - CIF any port



MACHINE REF :11265

Machines For Sale — . Gear, Grinder

MAKE :Niles WMW

MODEL :ZSTZ 10H (1985) 1250mm x 25 modul - CIF any port

SPECIFICATION :ITEM : GEAR GRINDING MACHINE MAKE : NILES WMW MODEL : ZSTZ 10H YEAR : 1985 Inspection under power is possible. Specification ： Max. wheel diameter : 1250mm Gear width : 430 mm Max. module : 2 - 25 Table diameter : 1000 mm Max helical angle : 45 ° Number of teeth : 10 ? 400 Max length of stroke : 25 - 450 mm Stroke position adjustment : 310 mm Double strokes : 70 - 190 1/min

DESCRIPTION :PRICE CIF ANY PORT
Quick View
,
NILES-MAGDEBURG Heavy Duty Lathe DP 3/3×20000, capacity DxL 2500×20000 mm, 3 off steadies (1979)

NILES-MAGDEBURG Heavy Duty Lathe DP 3/3x20000, capacity DxL 2500x20000 mm, 3 off steadies (1979)



MACHINE REF : 13015

Machines For Sale — Lathe, Conventional >=2m b/c

MAKE : NILES-MAGDEBURG Heavy Duty Lathe

MODEL : DP 3/3x20000, capacity DxL 2500x20000 mm, 3 off steadies

YEAR OF MANUFACTURE : 1979

CONTROLLER : conventional

SPECIFICATION : Swing over bed 2500 mm, Swing over cross slide 2000 mm, Swing in gap 3500 mm, Distance b/n centres 20000 mm, Max workpiece weight 30000 kg, Faceplate diameter 2500 mm Spindle diameter 100 mm, Spindle speeds range 0,45-140 rpm, Total power requirement 60 kW, Weight, ca. 64000 kg, 3 off steadies
Quick View
,
NING JIANG CNC Swiss Type lathes 3 off lathes CKN1112/II and CKN1120/11 (2009-2011) With C axis – Lot price

NING JIANG CNC Swiss Type lathes 3 off lathes CKN1112/II and CKN1120/11 (2009-2011) With C axis - Lot price



MACHINE REF :15441

Machines For Sale — . Lathe, CNC Sliding Head

MAKE :NING JIANG CNC Swiss Type lathes

MODEL :3 off lathes CKN1112/II and CKN1120/11 (2009-2011) With C axis - Lot price

CONTROLLER :SIEMENS 802C

SPECIFICATION :Mfg 1 x 2009 and 2 x 2011. One lathe is D12 turning diameter and 2 of them are D20 mm. Controller SIEMENS 802C. Condition is new. Never used in production!!!! Control SIEMENS 802C Turning dia D20 mm Turning length 200 mm Spindle speed 8000 rpm Spindle power 2,2/3,7 kW Bmvgcizo0c Max drilling diameter D10 mm Max tapping diameter M8 No of outer tools 6 pcs No of drills 4 pcs No of live tools 3 pcs Size of outer tools 10 x 10 mm (ca 100-120 mm length) Max speed of live tools 4500 rpm Power of live tools 0,4 kW Max dia of live tools D7 mm Spindle index 1 degree Power required 6 kW Weight ca. 1300 kgs Machine size LxWxH 1400 x 1000 x 1700 mm Accessories - Fix guide bushing - Rolling guide bushing - Coolant unit - Index C axis - Live tools - FMB Turbo 3 meter barfeeder - Pneumatic part catcher - Condition as new (it was never used in production)

DESCRIPTION :Price for Lot of 3 machines - Seller will split. Please ask for individual pricing.
Quick View
,
NKMZ 4-Rolls Plate Bending Rolls, excellent condition U-801, capacity on cold/hot bending 40/70×8000 mm, weight 540 t

NKMZ 4-Rolls Plate Bending Rolls, excellent condition U-801, capacity on cold/hot bending 40/70x8000 mm, weight 540 t



MACHINE REF :12311

Machines For Sale — . Sheet Metal & Plate, Bending Rolls

MAKE :NKMZ 4-Rolls Plate Bending Rolls, excellent condition

MODEL :U-801, capacity on cold/hot bending 40/70x8000 mm, weight 540 t

CONTROLLER :conventional
Quick View
,
NKMZ 4-Rolls Plate Bending Rolls, very good working condition – EXLOADED 801, capacity cold / hot 40 / 70×8000 mm, weight 427 t

NKMZ 4-Rolls Plate Bending Rolls, very good working condition - EXLOADED 801, capacity cold / hot 40 / 70x8000 mm, weight 427 t



MACHINE REF :12597

Machines For Sale — . Sheet Metal & Plate, Bending Rolls

MAKE :NKMZ 4-Rolls Plate Bending Rolls, very good working condition - EXLOADED

MODEL :801, capacity cold / hot 40 / 70x8000 mm, weight 427 t

CONTROLLER :conventional
Quick View
,
Noble and Lund CNC Gantry Mill 4 axis – 9m x 4.37m (between columns) x 2.4m under rail

Noble and Lund CNC Gantry Mill 4 axis - 9m x 4.37m (between columns) x 2.4m under rail



MACHINE REF :14359

Machines For Sale — . Mill, Plano/Gantry Type CNC

MAKE :Noble and Lund CNC Gantry Mill

MODEL :4 axis - 9m x 4.37m (between columns) x 2.4m under rail

SPECIFICATION :Between Columns 4370mm Max Height Under Bridge 2400mm Long Traverse 9000mm Traversing Table Size 3000mm x 3000mm (1st Unit) Rotary + Traversing Table Size 3000mm x 3000mm (2nd Unit) Width Across Bedways 2440mm Swivelling Ram With Universal Milling Head ISO50 Tooling + Milling Attachment Total weight of machine approx 90 tons.

DESCRIPTION :price includes dismantling and loading GE Century controller Working condition
Quick View
,
NOMOCO Centreless M100 (1985) – 100mm diameter max x 300mm – 400mm dia wheels

NOMOCO Centreless M100 (1985) - 100mm diameter max x 300mm - 400mm dia wheels



MACHINE REF :10924

Machines For Sale — . Grinder, Centreless

MAKE :NOMOCO Centreless

MODEL :M100 (1985) - 100mm diameter max x 300mm - 400mm dia wheels
Quick View
,
NOMOCO M100S

NOMOCO M100S



MACHINE REF :11615

Machines For Sale — . Grinder, Centreless

MAKE :NOMOCO

MODEL :M100S

SPECIFICATION :VERTICAL CENTERLESS “NOMOCO” Brand: Nomoco Model: M100S Description: - External grinding:max. grinding-Ø with/without steady rests110mm - min. grinding-Ø2mm - max. grinding lenfth for plunge grinding280mm - Grinding wheel:max. Ø 400mm - max. width280mm - boring203mm - fixture Ø203mm - flange- Ø260mm - cone- Ø (1:10)75mm - Total power consumption:22,97kW - Drive mode:3-phase current, 380 V, 50 Hz - Surface requirement: length x width x height1775 x 1940 x 1790mm - weight3500kg
Quick View
,
NORBLAST Sandblasting cabinet Good working condition, recently overhauled

NORBLAST Sandblasting cabinet Good working condition, recently overhauled



MACHINE REF :14912

Machines For Sale — . Finishing & Polishing

MAKE :NORBLAST Sandblasting cabinet

MODEL :Good working condition, recently overhauled
Quick View
,
NORMA CNC 5 AXIS MACHINING CENTRE 7m x 1.5m x 500mm – 2250mm between columns

NORMA CNC 5 AXIS MACHINING CENTRE 7m x 1.5m x 500mm - 2250mm between columns



MACHINE REF :5113

Machines For Sale — . Mill, Plano/Gantry Type CNC

MAKE :NORMA CNC 5 AXIS MACHINING CENTRE

MODEL :7m x 1.5m x 500mm - 2250mm between columns

CONTROLLER :NUM 750F

SPECIFICATION :Course: X 7000; Y 1500; Z 500 – Liftstroke: X 7000 ; Y 1500 ; Z 500 Passage entre-montants: 2250 – Gauge: 2250 Commande numérique NUM 750F – CNC NUM 750F Tête à renvoi d’angle, indexage 2.5° - Angle converter head, indexing 2.5° Magasin 32 outils iso 50 – 32 tools iso 50 Broche 19/24 KW – Pin 19/24 KW Actuellement en production – Currently in production

DESCRIPTION :Machine is in working order but would be ideal for retrofit.
Quick View
,
NORMA CNC Portal Milling Machine 5000 (1990) 4m x 1.2m – SIEMENS control (1990)

NORMA CNC Portal Milling Machine 5000 (1990) 4m x 1.2m - SIEMENS control (1990)



MACHINE REF :10851

Machines For Sale — . Mill, Plano/Gantry Type CNC

MAKE :NORMA CNC Portal Milling Machine

MODEL :5000 (1990) 4m x 1.2m - SIEMENS control

YEAR OF MANUFACTURE :1990

CONTROLLER :SIEMENS

SPECIFICATION :TABLE 970 X 4100mm DISTANCE BETWEEN COLUMN 1800mm SPINDLE TAPER ISO50 X STROKE 4000mm Y STROKE 1200mm Z STROKE 500mm

DESCRIPTION :PORTAL MILLING DRILLING MACHINE NORMA MODEL 5000 CNC SIEMENS VERTICAL HEAD AND ANGLE HEAD
