WALDRICH – COBURG MasterTec CNC portal machining centre X-5M Y-6.3M (2001)



MACHINE REF :2744

Machines For Sale — . Borer, Horizontal Floor CNC

MAKE :WALDRICH – COBURG MasterTec CNC portal machining centre X-5M Y-6.3M

YEAR OF MANUFACTURE :2001

SPECIFICATION :WALDRICH – COBURG MasterTec CNC portal machining centre
Built : 2001 + 2005
Type : MasterTec 3500
Control : Siemens Sinumerik 840 D
Dimensions :
Clearance between colums : 3500 mm
Clearance between table – vertical spindle nose : 3750 mm
Pallet size : 3000 x 4000 mm,
Max pallet loading : 40.000 kg
Travels :
Table / pallet ( X ) : 5000 mm
Milling- and boring unit ( Y ) : 6375 mm
Ram, vertically ( Z ) : 1250 mm
Crossrail, vertically ( W ) : 2750 mm
Milling- and boring unit :
Power : 63 kW
Speed range : 5-900 / 28-5000 min-1
Max. torque : 3300 Nm
– Automatic mounting of spindle units
– Automatic indexing of spindle units 360°, 0,5° steps
Equipment / accessory :
– 200 stations automatic tool changer per machine
– Inner coolant supply 70 bar
– Central coolant tank 4000 l
– Centrifuge filter
– Automatic serving system for 6 spindle units per machine
– Heads ( together for both machines )
2x straight 150mm long
2x straight 700mm long
2x angle 90º 500mm
2x Boring – and facing unit 1050 mm
1x Boring – and facing unit 1350 mm
– Pallets together 5 pcs.
– About 500 tools with holder, accessory, etc.
pictures, drawings and documentation available !
Condition : Very well machines, can be seen under full power.
Description Original price of the machines ( without installation, basement, TOOLS, etc ): 6.376.000,- EUR
Controller Siemens Sinumerik 840 D

Categories: ,

Description

WALDRICH – COBURG MasterTec CNC portal machining centre X-5M Y-6.3M (2001)



Price: Write Us

Date of Offer :
Location : Europe - Western
Quantity : 1
Availability : 14 Mar 2010
